The diagram illustrates the structure of a simple solar panel system and how it works.

Overall, this is a linear process, which consists of 3 steps. It starts from a box with a Transparent Top, and ends with the solar panel to heat water.

Initially, there can be seen a box with two pipes. The left one is called inlet, and the right one is outlet. There is also a glass which is rectangular in shape. It is a special Transparent Top. When sun rays starts to heat this glass, it absorbs heat energy. After that, cool air enters to the box through inlet, and by outlet warm air is out.

During the second stage, cool air which first entered, then became warm because of the heat that Transparent Top provided from sun rays. In the last stage, this logic is still same, but instead of air there is water. Cool water enters the box by inlet, and warm water leaves it from outlet. It is a water pipe included into the box, which gets heat energy from the glass and heats cool water.
